Award-Winning Performance.
Unmatched Value.
Our Award-Winning e-gravel machine has not compromised on weight, strength, quality, or tyre size. We have collaborated with gravel riders to create the ultimate ride, allowing them the freedom to explore and conquer any terrain put in front of them.
The combination of our light-weight carbon frame, gear set and powered by the DJI Avinox motor system makes the Phantom the fastest and most versatile e-gravel bike on the market.
Â
Â
Frame & Fork
- Carbon fibre monocoque frame
- Carbon gravel fork
- Integrated 600 Wh battery
- Internal cable routing
- 8 mounting points for bikepacking and accessories
- UDH compatible
- Clearance for up to 50c tyres
- 12 × 100 mm front / 12 × 142 mm rear thru-axles
Motor & Battery
-
DJI Avinox M2
- 250 W nominal power
- 120 Nm continuous torque
- 125 Nm Boost mode
- 1,100 W peak power
- 600 Wh integrated battery
- DJI Avinox DP100 2-inch OLED touchscreen display
- Wireless Bluetooth controller
- 4A fast charger
Drivetrain
-
SRAM Rival XPLR AXS E1 wireless 13-speed
- SRAM XG-1351 E1 10–46T cassette
- Avinox SL 165 mm cranks
- Velduro 44T alloy chainring
Brakes
- SRAM Rival hydraulic disc brakes
- SRAM HS2 160 mm rotors front and rear
Wheels & Tyres
- Velduro carbon wheelset
- Sapim Race double-butted spokes
- Maxxis Rambler 700 × 45c tyres
- Tubeless-ready
Cockpit
- Velduro carbon handlebar
- 420 mm (S/M)
- 440 mm (L/XL)
- FSA SMR alloy stem
- Fizik Terra Aidon X5 saddle
- RockShox Reverb AXS XPLR 27.2 mm wireless dropper post with 50 mm travel
|
